Corrugated Pe Pipe Extrusion Machine , High output Plastic Pipe Machine
Quick detail:
PE plastic single-wall corrugated pipes produced by our single wall corrugated pipe machine have many features such as high intensity, good flexibility,high temperature resistance, resistant to corrosion and abrasion, etc. They has large market which are widely used in the fields of auto wire, electric thread-passing pipes,protective pipes of lamps and lanterns wire, circuit of machine tool, tubes of air conditioner and washing machine and so on.
Description:
1. Plastic corrugated pipe production line is used for continously producing single wall and double wall corrugated pipe . Plastic corrugated pipe is resistant to high tempreture ,corrosion and abrasion ,very flexble .They are widely uesed in feild of autowire ,electric wire protection ,lamp circuit protection ,tubes of air condition and washing machine etc.
2. High precision and character for forming machine and head die. Water and wind cooling for moduleOn-line belling. Unique digital control system . High automatic, high output, stable production condition.
3. PE single wall corrguated pipe production line adopts complicated mechanic head ,double combiated machine to production to provide material and spiral writhe . The forming system of this line consists of mould and corrugator.The mould blocks can be easily changed and they may have air or water cooling system.
Specifications:
| Diameter Scope | 4.5-9 | 9-32 | 32-50 |
| Main Extruder | SJ-30 | SJ-45 | SJ-65 |
| L/D | 30:1 | 30:1 | 30:1 |
| Output kg/h | 10 | 40 | 80 |
| Main Motor Power kw | 4 | 11 | 18.5 |
| Corrugator Power kw | 1.1 | 1.5 | 1.5 |
| Mould Block Pairs | 42 | 44 | 44 |
| Cooling Type | Water and air cooling |
| Linear Speed (m/min) | 6-10 | 8-12 | 8-15 |
| Counting Type | Sensing counting |
| Winding Type | Automatic/Manual |
Applications:
They has large market which are widely used in the fields of auto wire, electric thread-passing pipes,protective pipes of lamps and lanterns wire, circuit of machine tool, tubes of air conditioner and washing machine and so on.
Competitive Advantage:
1.high temperature resistance . high intensity. corrosion resistance etc.
2.high quality and reasonable price
3. our engineers availiable to serive go abroad , and if clients need , we can train the local workers until they can use the machine.
